Description Technical Specifications Category Parameter Description Wireless Performance   Protocol   IEEE 802.11ah (902-928 MHz) IEEE 802.11 b or g or n (2412-2472 MHz) Communication Bandwidth 8 MHz Data Rate Maximum 16 Mbps Receiving Sensitivity 1 M PPDU MCS=10 -105 dbm; 8 M PPDU MCS=0 -95 dbm; 8 M PPDU MCS=7 -81 dbm Number of Supported Network Nodes Up to 8 Access Points Transmit power 20 dBm 100 mW Commissioning mode BPSK, QPSK,QAM16 or QAM64 Transmission Distance Maximum 1000 meters for intervisibility, 300 meters for non-intervisibility Security specification   WPA2-PSK Encryption AES Hardware Hardware 10 or 100 Mbps Power Supply Type-C 5V/1A     LED Indication Power Indicator Connection Indicator Link Building Indicator Antenna Interface Built-in Antenna Electrical Performance Input Voltage 5 V 1A Maximum Current 500 mA Average Power Consumption 1.5 Watt Operating Temperature  −4 °F to 158 °F    (-20 °C  to 70 °C) Storage Temperature   −22 °F to 176 °F  (-30 °C  to 80 °C) Operating Humidity 10%   to   90% Storage Humidity 5%   to   95% Dimensions Product Size   2.09 in (Diameter)  x 0.73 in (Height)        (53 (Diameter) x 18.6 (Height) mm) Product Weight 0.2 lbs (120 g)
