Description Technical Specifications Application Smart cities and communities LoRaWAN Protocol Class A / Class B / Class C Memory 1.2GHz 4GB / 8GB eMMC Flash 1GB LPDDR2 SDRAM Processor Broadcom BCM2837B0, Cortex-A53 (ARMv8) 64-bit SoC Frequency 433 / 470 / 868 / 915 / 923 Communication Distance 6.21 miles (10 km) Ingress Protection IP67 Backhaul Connectivity 4G/ETH Spreading Factor SF7 to SF12 Transmit Power Max 26 dBm Receiving Sensitivity -135 dBm at SF10 at BW125kHz Operating Voltage 11V to 36V DC, 44V to 57V DC (PoE) Static Power 3.8W Configuration Method Ethernet / Wi-Fi Configuration Interface WEB Status Monitoring Power supply voltage, built-in UPS voltage and charging, CPU and motherboard temperature, CPU and memory usage rate Nodes Up to 200 Transmission Distance Up to 6.21 mi (10 km) Ingress Protection IP67 Power Supply PoE Solar Power Supply Normal Operation Power Consumption 3.8 W Full Load Peak Power Consumption 5 W N1 GPS antenna interface N-Female N2 LoRa antenna interface N-Female N3 2.4G antenna interface N-Female N4 4G antenna interface N-Female P1 DC power supply, debugging lin See the table below for details P2 PoE interface Black GND DC power supply negative Red VCC DC power supply positive Yellow RXD RS-232 console White TXD Green DEF Reset Operating Temperature -13 °F to 176 °F (-25 °C to 80 °C) Product Size 2.70 in x 8.27 in x 2.26 in x 0.65 in (6.86 cm x 21 cm x 5.75 cm x 1.65 cm)
