Advanced LoRaWAN Gateway for 4G, Ethernet, and Wi-Fi Wireless Data Transmission – GAOTek

Description Overview GAOTek advanced LoRaWAN Gateway is an outdoor gateway based on the low-power wide area network LoRaWAN protocol, which can connect to standard LoRaWAN terminals and perform two-way communication. The gateway connects the gateway device to the NS (network server) through standard Ethernet and supports network and firewall functions. At the same time, it supports 2.4G Wi-Fi and LTE (optional) for uplink communication connection. It supports the MQTT Bridge function and can be connected to a third-party platform through MQTT Integration.   Features LoRa supports 8RX 1TX channels Support 2.4G Wi-Fi 100M base-T Ethernet supporting PoE Support Ethernet, Wi-Fi or LTE uplink multi-link backup Open WRT software program that supports LoRaWAN and network configuration Built-in radiator for heat dissipation Access to private or public (TTN) LoRa network server Support TF card storage method Suitable for use at indoor ambient temperature Support optional LTE 4G function support   Technical Specifications Processor MT7 628, DDR2RAM 128 MB   Wi-Fi Function Frequency: 2.400 GHz to 2.4835 GHz (802.11 b/g/n) RX sensitivity: -95 dBm (minimum), TX power: 20 dBm (maximum) Operating channel: 2.4 GHz: 1 to 13   LoRa Function SX1301 Mini PCIe card 8 lanes RX sensitivity: -142 dBm (minimum), TX power: 27 dBm (maximum) Frequency: EU 433, CN 470, EU 868, US 915, AS 923, AU 915, KR 920, IN 865  Mobile Cellular Network Support optional Quectel EG95-E/EG95-NA: LTE CAT 4 network, not supported by default   Power Supply DC 12V to 1A   Power Consumption 12 W (typical value)   Ethernet RJ 45(10/100 M)   Console RJ45 (RS232)
