Description Specifications: Product Name G1000 G850 G750 G650 Model Number HAT-1000yzB2G HAT-850yzB1G HAT-750yzB1G HAT-650yzB1G Output Power 1000W 850W 750W 650W Form Factor ATX 3.1 Modularity Fully Modular Dimensions 150 x 150 x 86mm (L×W×H) Color Black and White 80PLUS Certification Gold Efficiency >90% @ Typical Load (50% Load) AC Input 100-240Vac Fan Size 140mm Fan Bearing FDB Capacitors Main Japanese Capacitor Operating Temperature 0-50°C Protection OTP / OCP / OPP / SCP / OVP / UVP / SIP/ NLO Safety CE / TUV / cTUVus / FCC / ICES / UKCA / EAC Environmental Compliance RoHS / WEEE / ErP 2014 MTBF 100,000 Hours Connectors MB ATX 24 Pin x 1 CPU (4 4) Pin x 2 PCI-E (6 2) Pin x 3 12V-2×6 (12 4) Pin x 1 SATA x 8 Molex 4 Pin x 4 MB ATX 24 Pin x 1 CPU (4 4) Pin x 2 PCI-E (6 2) Pin x 3 12V-2×6 (12 4) Pin x 1 SATA x 6 Molex 4 Pin x 2 MB ATX 24 Pin x 1 CPU (4 4) Pin x 2 PCI-E (6 2) Pin x 3 12V-2×6 (12 4) Pin x 1 SATA x 6 Molex 4 Pin x 2 MB ATX 24 Pin x 1 CPU (4 4) Pin x 2 PCI-E (6 2) Pin x 2 12V-2×6 (12 4) Pin x 1 SATA x 6 Molex 4 Pin x 2
