Display System Display System SXRD panel, projection system Display device Size of effective display area 0.61” x 3 Number of pixels 6,220,800 (1920 x 1080 x 3) pixels Projection lens Focus Manual Zoom Manual (Approx. x1.6) Lens shift Manual, Vertical: /- 71%, Horizontal: /- 25% Light source Light source High-pressure mercury lamp, 215 W type Recommended lamp replacement time *1 Recommended lamp replacement time 6000 H (Lamp mode: Low) Filter replacement cycle (Max.) Filter replacement cycle (Max.) Same time as the lamp replacement is recommended Screen size Screen size 40” to 300” (1,016 mm to 7,624 mm) Light output Light output 1800 lm (Lamp mode: High) *2 Colour light output Colour light output 1800 lm (Lamp mode: High) *2 Contrast ratio Contrast ratio 120,000:1 (Dynamic Contrast) Displayable scanning frequency Horizontal 19 kHz to 72 kHz Vertical 48 Hz to 92 Hz Display resolution Computer signal input Maximum display resolution: 1920 x 1080 dots (HDMI Input only) Video signal input 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i The following items are available for HDMI input only. 1080/60p, 1080/50p, 1080/24p OSD language OSD languages 17-languages (English, Dutch, French, Italian, German, Spanish, Portuguese, Russian, Swedish, Norwegian, Japanese, Simplified Chinese, Traditional Chinese, Korean, Thai, Arabic, Polish) INPUT OUTPUT (Computer / Video / Control) HDMI1 / HDMI2 Digital (RGB/Y Pb/Cb Pr/Cr) Trigger Minijack, DC 12 V Max. 100 mA Remote RS-232C, D-sub 9-pin (female) LAN RJ45, 10Base-T/100BASE-TX IR IN Mini Jack USB DC 5 V, Max. 500 mA Acoustic noise Acoustic noise 22 dB Operating temperature / Operating humidity Operating temperature / Operating humidity 5°C to 35°C (41°F to 95°F) / 35% to 85% (no condensation) Storage temperature / Storage humidity Storage temperature / Storage humidity -20°C to 60°C (-4°F to 140°F) / 10% to 90% (no condensation) Power requirements Power requirements AC 100 V to 240 V, 3.1 A to 1.3 A,50/60 Hz Power consumption Power consumption Max 310 W Power consumption (Standby) Power consumption (Standby) 0.4 W Standby Mode Activated Standby Mode Activated After about 10 Minutes Dimensions (W x H x D) (without protrusions) Dimensions (W x H x D) (without protrusions) 407.4 x 179.2 x 463.9 mm 16 1/8 x 7 1/8 x 18 3/8 inches Mass Mass Approx. 9 kg / 20 lb Supplied accessories Supplied accessories RM-PJ28 Remote Commander (1) Size AA (R6) Manganese Batteries (2) AC Power Cord (1), Lens Cap (1) Operating Instructions (CD-ROM) (1) Quick Reference Manual (1) Optional Accessories 3D Glasses Please contact your Sony representative for specific models available in your region. Replacement lamp Replacement lamp LMP-H210 Notes *1 The figures are expected maintenance time and not guaranteed. They will depend on the environment or how the projector is used. *2 The values are estimate. Environmental notice for customers in the USA Lamp in this product contains mercury. Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or see www.sony.com/mercury for additional information.
