HI-PERFORMANCE INJECTABLE ANCHORING ADHESIVE 390 ML CARTRIDGE | HORSE HM-500 | NASIR & SONS

Description: HM-500 injectable chemical anchor is a fast curing,multi-purpose, two components modified epoxy resinanchor system for threaded bars and reinforcing barsin both cracked and uncracked concrete. Application Range ■ Planting steel bars and bolts in concrete structure ■ Curtain wall & stone dry hanging brackets’reinforcement ■ Building structure reinforcement&frameworkanchoring ■ Various equipments’ basic fixation ■ Steel structures and concrete structures anchoringconnection ■ Reinforcement for highway, bridges, waterconservancy projects rebuilding ■ Reinforcement for advertisement boards,the noisebarriers&barricades   Advantages ■ Modified epoxy resin, no styrene ■ High strength & modulus, good toughness Aging resistance & thermal resistance ■ Moisture tolerant, stable in a humid environment ■ Acid & alkali resistance ■ Seismic resistance, no expansion forces ■ Excellent thixotropy, suitable for side and topanchoring ■ Binocular straight mixed package, with specialelectric caulking gun and static mixer   The Detailed Construction Process of HM-500 Structure Anchor Adhesive : 1.Drill Hole 2.Brush 3.Blow 4.Inject 5.Plant 6.Curing Construction Process : 1. Mark Up Hole Position and Drill Hole: Drill holes in designed position. The depth and dismeter of the hole should meet the requirements in orderto meet bonding area and ensure the pulling strength. 2. Clean Hole:Clean and blow holes. Brush and blow for three times at least is recommended. 3.Glue Preparation:HM-500 is equipped with a special static mixer and dispenser. Squeeze out the glue without fully mixed inthe front part of the cartridge. 4.Injection:Inject the glue from the bottom of the hole untill fill the two-third of the hole. 5.Rust Removal of Steel Rebar:Polish the steel bar or anchor bolt before inserted through the hole. 6.Anchoring:Inserting in one single direction untill to the bottom of the hole. 7.Standing and Curing:Keep stand for maintenance before curing. Note:HM-500 Anchoring Adhesive can be equiped with the following materials: screw thread steel, round steel,lead screw,threaded rod, anti-crack anchor. Attention Proctive measures such as wearing masks, gloves,goggles etc., is necessary. Do not expose outside forlong time.If it is swallowed or dipped into eyes, pleaseseek medical service at once
