Cudy AX3000 Wi-Fi 6 Mesh Kit 3 Pack – White

DescriptionFEATURES:1.3 GHz Dual-Core CPU4-Stream Dual-Band Wi-Fi 62402Mbps 574Mbps Wi-Fi 1200 Connected Devices 2Fast RoamingCudy Mesh, VPN Server and ClientMulti-Band Simultaneous BackhaulCudy App, Cloud ControlContains 3 x Mesh UnitsSPECIFICATIONS:Chipset: MT7981CPU Details: 1.3 GHz Dual-Core, ARM Cortex-A53Flash/ROM: 128 MB (1Gbit) NANDDDR/RAM: 256 MB (2Gbit) DDR35.0GHz Wi-Fi Speed: 2402Mbps2.4GHz Wi-Fi Speed: 574Mbps5.0GHz Wi-Fi Streams: 2T2R (2×2 MIMO)2.4GHz Wi-Fi Streams: 2T2R (2×2 MIMO)Wi-Fi Antennas: 5× Internal5.0GHz Antenna Gain Max: 5.1dBi2.4GHz Antenna Gain Max: 4.2dBiFEM or PA/LNA: 5 GHz: 3× Internal | 2.4 GHz: 2× InternalBeamforming: TrueRange Performance: Max: 220 m (722 ft) Indoor Wi-Fi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions.Wall Performance: Two wooden walls with thickness < 10 cm (4”) | One concrete wall with thickness < 20 cm (7”) or two concrete walls with thickness < 10 cm (4”)Multi-Pack Indoor Coverage:2 Pack: 400 m² (4300 sq ft)3 Pack: 600 m² (6500 sq ft)Applied to wireless backhaul situation. Place in the center of each floor, with a maximum of three obstacles to each room.Interfaces2.5G RJ45 Ports: 1Gigabit RJ45 Ports: 1Ethernet Notes: The 2.5G port is WAN port, the Gigabit port is LAN portLED: System | Speed/Link/ACT of Ethernet PortPhysical Buttons: WPS Button | Reset ButtonPower Input: DC JackPower Methods: DCDC: 12V 1APower Adapter: Input: 100 ~ 240 V, 50/60 Hz AC | Output: 12V 1A DCOperating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)Humidity: 10% ~ 90% non-condensingStorage Humidity: 5% ~ 95% non-condensingCertifications: FCC, CEProduct Dimensions: 11 x 15.4 cmProduct Weight: 360gWHAT’S IN THE BOX:Cudy AX3000 Mesh Wi-Fi 6 System – White x3Power Adapter x3Ethernet Cable x1Installation Guide x1
